Choosing the Right Packaged Pump Station for Your Needs

At Pump Stations Direct, we specialise in delivering pump station packages designed to suit a range of budgets and applications. Whether you need a small system for light residential stormwater management, a medium residential sewage system, or a large option for heavy residential applications, we have you covered.

Our online selector tool simplifies customising a pump station package to meet your project’s specific requirements, while also providing cost estimates for stormwater or sewer pump stations to streamline budgeting and planning.

We’ve created pre-packaged pump station examples that feature single sump pump systems; however, all our chambers—except the 280L—are suitable for dual sump pump systems, offering flexibility for urban, residential and commercial needs. Let’s take a closer look at three of our most popular packaged pump station design examples, each tailored to a different application.

1. Small Residential Pre Packaged Stormwater Pump Station

Ideal for small urban and residential stormwater management, our 250L Stormwater Pump Station is perfect for rainwater or greywater in homes and light-use environments, meeting small stormwater pump station design needs.

Image is representative only

Our most compact pump station package is both affordable and highly efficient, and includes:

• A PSD32-55 single submersible drainage pump that has a max flow of 3.6 L/s and a max head pressure of 11.5 m.
• A PS02A chamber with 250L capacity - 960 mm depth and a 615 mm diameter, perfect for tight spaces.
• A 560 mm diameter non-trafficable poly cover, suitable for backyards.
• High-level alarm is optional but recommended.

The simplicity of this packaged pump station makes it perfect for homeowners or developers looking for a cost-effective solution to manage stormwater drainage. Its compact size offers easy installation and exemplifies efficient stormwater pump station design.

2. Medium Residential Pre Packaged Sewer Pump Station

Our mid-range packaged pumping stations are better suited for medium-scale residential sewage systems. This 950 L pre-packaged sewer pump station is a balance between affordability and capability, providing an excellent sewage pump station design for residential applications.

This system includes:

• A PSG50-150W single submersible grinder pump with a max flow of 5.5 L/s at 0.2 m head, ensuring reliability with built-in redundancy.
• A PS09 chamber with 950 L capacity - 1440 mm depth and a 1000 mm diameter, making it suitable for medium-large sized properties.
•  A 600 mm x 600 mm light-duty Class B cast iron cover for light vehicle traffic.
• HLA high-level alarm is optional but recommended.

This mid-range single pump pump station package offers excellent value for customers seeking a cost effective yet reliable solution for medium residential sewage systems. This chamber is also suitable for a dual sewage pump system if required. With its customisable setup, it’s a perfect sewage pump station design example, balancing sewer pump station cost and efficiency.

3. Large Residential Pre Packaged Sewer Pump Station

Our largest of the pre-packaged pumping station range is ideal for heavy residential or light commercial applications with high demand, as they're tailored to deliver reliable, heavy-duty performance. Whether you’re managing wastewater for a large home or a small to medium sized residential complex, these systems deliver exceptional capacity and durability.

Image is representative only

Key features include:

• A PSG50-150W single submersible grinder pump, with a max flow of 5.5 L/s at 0.2 m head.
• A PS61chamber with 6100 L capacity - 2400 mm depth and 1950 mm diameter, accommodates substantial water storage needs.
• A 900mm x 600mm light-duty Class B cast iron cover built to withstand high traffic, including roads and driveways.
• HLA high-level alarm optional but recommended.

These sewage pump station packages are versatile, reliable, and ideal for heavy wastewater or light commercial applications. They also showcase optimal sewage pump station design for large-scale projects.

Why Choose a Packaged Pump Station?

Opting for a packaged pump station simplifies installation. Each unit is pre-configured, ensuring efficiency and reliability. Plus, with options ranging from budget-friendly to top of the range, we have solutions for every light-heavy residential application.

Popular applications for packaged pump stations:

• Light residential stormwater management.
• Medium sewage management.
• Heavy domestic-light commercial sewage and stormwater systems.

Our online selector tool is designed to guide you in choosing the perfect pump station package for your domestic project. From light-heavy residential needs to light commercial solutions, you can customise your packaged pumping station to meet your exact requirements. Create an account, use the selector tool to get a cost estimate, and find the solution that’s right for you!
